MH20

MSRP

$13,295.00$17,995.00

Choose an option
MH20 – MH20
$13,295.00

In stock

MH20 – MH20DIESEL
$17,995.00

In stock

MH20 – MHE20-230V-1/PH
$16,135.00

In stock

MH20 – MHE20-230V-3/PH
$15,885.00

In stock

MH20 – MHE20-460V-3/PH
$15,885.00

In stock

MH20 – MHE20-600V-3/PH
$16,135.00

In stock

Clear

Share your thoughts!

Let us know what you think...

Only logged in customers who have purchased this product may leave a review. Log in now

What others are saying

There are no contributions yet.

×

Continue as a Guest

Description

Specifications

Options
Capacity Icon

6 to 7 bag capacity or 20 cu.ft. (.57 m3) - ¾ cubic yard

Mix up Icon

11.7 HP Honda Gas Engine (Standard)

Weight Icon

Will mix up to 3/4" (1.9 cm) aggregate

Hydraulic Icon

Discharges up to 51" high

Recoil Start Icon

Empty weight 2295 lbs. (1041 kg)

Dimension Icon

Gross weight 5295 lbs. (2406 kg)

Engine Icon

Hydraulic dump system

Thickness Icon Copy

Hydraulic drive system

Weight Icon

Manual recoil and electric start

Hydraulic Icon

3/8" drum end and 5/16" drum wrap thickness

Thickness Icon

Overall dimensions (L × W × H) 94.25" x 44" x 53"

  • 10 HP Electric Motor - 1PH/230V

  • 10 HP Electric Motor - 3PH/230V

  • 10 HP Electric Motor - 3PH/460V

  • 9.5 HP Kubota Diesel Engine

  • Solid grating available to minimize dust

  • Water bar for easy filling - optional, re-settable meter

Comparison

MH20 MH20DIESEL MHE20-230V-1/PH MHE20-230V-3/PH MHE20-460V-3/PH MHE20-600V-3/PH

  Dimensions

(L × W × H)
94.25" x 44" x 53"

(L × W × H)
94.25" x 44" x 53"

(L × W × H)
94.25" x 44" x 53"

(L × W × H)
94.25" x 44" x 53"

(L × W × H)
94.25" x 44" x 53"

(L × W × H)
94.25" x 44" x 53"

  Capacity

6 to 7 bag capacity or 20 cu.ft. (.57 m3) - ¾ cubic yard
6 to 7 bag capacity or 20 cu.ft. (.57 m3) - ¾ cubic yard
6 to 7 bag capacity or 20 cu.ft. (.57 m3) - ¾ cubic yard
6 to 7 bag capacity or 20 cu.ft. (.57 m3) - ¾ cubic yard
6 to 7 bag capacity or 20 cu.ft. (.57 m3) - ¾ cubic yard
6 to 7 bag capacity or 20 cu.ft. (.57 m3) - ¾ cubic yard

  Gross Weight

5295 lbs. (2406 kg)
5295 lbs. (2406 kg)
5295 lbs. (2406 kg)
5295 lbs. (2406 kg)
5295 lbs. (2406 kg)
5295 lbs. (2406 kg)

  Thickness

5/16" drum thickness
5/16" drum thickness
5/16" drum thickness
5/16" drum thickness
5/16" drum thickness
5/16" drum thickness

  Engine

11.7 HP Honda Gas Engine (Standard)
11.7 HP Honda Gas Engine (Standard)
11.7 HP Honda Gas Engine (Standard)
11.7 HP Honda Gas Engine (Standard)
11.7 HP Honda Gas Engine (Standard)
11.7 HP Honda Gas Engine (Standard)

 Hydraulic Pumps

Yes

Yes

Yes

Yes

Yes

Yes
